Applied for | Oil |
Suitable for | PET bottles |
Production capacity | 3000BPH~12000BPH |
Filling system | Gravity filling, weigh filling |
Material | Stainless steel 304(SUS 316 can be customized) |
Color | Can be customized |
Standard | ISO SGS CE |
The oil filling and capping are intergrated in one machine. Our machine is fully automatic and have scientific and reasonable design. Also with beautiful appearance and complete functions, it's easy to operate and maintain. We all use advanced German technology and Italian technnology.
Bottle changing is easy. There is no need to adjust the height of machine through neck holding tech for bottle trans portation. And what is only to change the spare parts.
The bottle goes through filling and capping with little abrasion. High speed filling valve assures high speed and exact liquid level control.
We all use 304 stainless steel or food level material to ensure the high quality of our machine. PLC control system is used and electric parts are using famous brand like Mitsubishi Siemens Schneider and so on.
Oil filling machine parameter | ||||||
Filling Volume | 500ml as standard (the capacity will be different if use other bottle size ) | |||||
Bottle Type | Round or square PET bottle | |||||
Voltage | 3 phase 380V/50HZ(can be customized) | |||||
Filling Precision | <0.5% | |||||
Air Pressure | 0.5-0.7Mpa | |||||
Model | 12-5 small bottle | 16-5 small bottle | 24-8 small bottle | 32-8 small bottle | 12-5 big bottle | 20-5 big bottle |
capacity | 3500BPH | 5500BPH | 8000BPH | 11000BPH | 1200BPH | 1800BPH |
Weight | 1000kg | 1500kg | 1800kg | 2000kg | 3000kg | 3600kg |
Size of whole machine (length×width×height) | 2100*1600*2500mm | 2300*1700*2500mm | 2400*1900*2500mm | 2900*2100*2500mm | 4000*2300*2500mm | 4600*2500*2500mm |
