SF-B-I
SANOFI
Specification:
SF-B-1 semi-automatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 50-2000ml. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.
●Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.
●The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
●The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
●The machine can be operated in the step-by-step mode and the semi-auto mode.
●The machine is small with low investment, easy and safe to operate
Main Technical parameter:
TYPE | ITEM | UNIT | TECHNICAL DATA |
CONTAINER | Product material | PET/PC/PP | |
Container volume | L | ≤2 | |
Theoretical Output | Pcs/hr | 800BPH | |
Max. bottle height | mm | 360 | |
Max.bottle diameter | mm | 120 | |
| Max.moula plate dimension(LxW) | mm | 340 |
Max.mould thickness of mould | mm | 200 | |
Clamping force | KN | 80 | |
Mould opening stroke | Mm | 150 | |
AIR COMPRESSOR | Working pressure | Mpa | 0.8-1.0 |
Air compressor for blowing | Mpa | 2.0-3.0 | |
MACHINE SIZE AND WEIGHT | Main machine(LxWxH) | M | 1500×600×1750 |
Main machine weight | KG | 660 | |
SAFETY | SAFETY INTER-LOCKING DEVICE | Auto-emergency alarm | |
Specification:
SF-B-1 semi-automatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 50-2000ml. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.
●Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.
●The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
●The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
●The machine can be operated in the step-by-step mode and the semi-auto mode.
●The machine is small with low investment, easy and safe to operate
Main Technical parameter:
TYPE | ITEM | UNIT | TECHNICAL DATA |
CONTAINER | Product material | PET/PC/PP | |
Container volume | L | ≤2 | |
Theoretical Output | Pcs/hr | 800BPH | |
Max. bottle height | mm | 360 | |
Max.bottle diameter | mm | 120 | |
| Max.moula plate dimension(LxW) | mm | 340 |
Max.mould thickness of mould | mm | 200 | |
Clamping force | KN | 80 | |
Mould opening stroke | Mm | 150 | |
AIR COMPRESSOR | Working pressure | Mpa | 0.8-1.0 |
Air compressor for blowing | Mpa | 2.0-3.0 | |
MACHINE SIZE AND WEIGHT | Main machine(LxWxH) | M | 1500×600×1750 |
Main machine weight | KG | 660 | |
SAFETY | SAFETY INTER-LOCKING DEVICE | Auto-emergency alarm | |
