Whether you produce craft beer, lager, or wheat beer, our professional expertise helps you achieve optimal results with advanced technical knowledge and complete packaging solutions.
Beer Bottling Machine
Beer Canning
Machine
Water Filling Production Line ADVANTAGE
Diverse Water Treatment Systems: We provide tailored water treatment solutions for different raw water qualities.
1：Water treatment features a new vertical pipeline design, which is elegant and practical.
2:The system uses pneumatic valves for automatic control, with a complete Siemens control system, Dahuan ozone system, Philips UV lamps, FRP membrane housings, ABB inverters, and full system flow diagrams.
3:The filling line is equipped with a complete lubrication system for conveying components, extending service life.
4:The filling system includes Italian imported pumps, ABB motors, Siemens control systems, and food-grade 304/316 stainless steel.
5:We also customize high-speed air-assisted filling valves to greatly improve filling speed.
Parameters Table
Model
Capacity (BPH)
Bottle Size (H×D)
Total Power(kw)
Overall Dimensions
Weight (kg)
BGF16-12-6
1500-2500
H=170-320,D=50-100
1.5+0.37
2300*1680*2650
2600 kg
BGF18-18-6
2500-4500
H=170-320,D=50-100
2.2+0.37
2500*1760*2650
3500 kg
BGF24-24-8
4500-6000
H=170-320,D=50-100
3+0.45+0.25
3100*2100*2650
4650 kg
BGF32-32-8
6000-8000
H=170-320,D=50-100
5.5
3800*2800*2650
6800 kg
BGF40-40-40
8000-9000
H=170-320,D=50-100
7.5
4000*3300*3400
8500 kg
Main feature
1. It uses air conveyor & starwheel direct connection; screws and conveyor chains are eliminated, making bottle format changeover much easier.
2. Bottles are transferred by neck gripping. No need to adjust machine height for format change; only replace relevant arc guides, starwheels and nylon parts.
3. The specially designed stainless steel bottle washing gripper is sturdy and durable, with no contact on the bottle mouth thread to avoid secondary contamination.
4. High-speed gravity filling valves enable fast, accurate filling with no liquid spillage.
5. Bottles exit via spiral descent; no need to adjust conveyor height for bottle changeover.
6. The main machine uses advanced PLC automatic control. Key electrical components are sourced from well-known brands: Mitsubishi (Japan), Schneider (France), Omron (Japan).
FAQ
Are you a factory? How many employees do you have?
Yes,we are factory. our factory is located in zhangjiagang near from shanghai. We have about 50 workers in our factory.
What about after sale service?
What about installation?
What do we do if we encounter problem about the machine ?
How can you control the quality and delivery?
Success in water beverage production requires focus on maximum output and efficiency, with commitment to hygiene, food safety, cost optimization and sustainability.
Bottle Filling System
Filling
Filling machines are designed to accurately and efficiently fill containers with liquid or semi-liquid products.
Labeling&Packing
Labeling machines are used to apply labels onto containers, such as bottles, cans, or boxes and then the bottles are packaged with PE film or cartons for easy transportation.
Water Purification
Raw water passes through a water purification system to produce clean water for drinking, filling, transportation and storage.
Blowing
Blowing machines are used in the packaging industry to make plastic containers, such as bottles or jars.
